sE Electronics X1 S

Large-diaphragm Cardioid Condenser Microphone, with -10dB/-20dB Pad and Low-cut Filters
Product Highlights
  • Cardioid Polar Pattern
  • Pressure-Gradient Design
  • Handcrafted Gold-Sputtered Capsule
  • 20 Hz to 20 kHz Frequency Response
  • Switchable -10 dB or -20 dB Pad
  • Selectable 80 Hz or 160 Hz Low-Cut Filter
  • High Maximum SPL
  • Metal Housing
  • Gold-Plated XLR Connector
  • Includes Mic Clip

  • Overview
  • Tech Specs

The X1 S is a refined version of sE's best-selling X1, tuned for advanced performance in every way imaginable.

With the highest dynamic range and SPL handling capabilities in its class, along with expanded features that dramatically increase its flexibility, the X1 S has been improved in every way - yet is even more affordable than the original.

HIGH-PERFORMANCE ELECTRONICS
Where the original X1 was powerful, the redesigned electronics of the X1 S take its performance to a whole new level, giving it the highest dynamic range in its class.

Its internal redesign also allows for improved sensitivity, dramatically increased SPL handling (up to 160dB!), and a huge reduction in self-noise.

TWO SWITCHABLE ATTENUATION LEVELS
The -10 dB and -20 dB pad switches provide extended dynamic range, enabling a wide range of applications and close-mic techniques for even the loudest instruments...think super-heavy electric guitars, fortissimo brass instruments, and heavy-footed kick drums.

TWO SWITCHABLE LOW-CUT FILTERS
Selectable at either 80Hz or 160Hz, these two filters help eliminate low-frequency rumble or footfall noise, as well as help compensate for excessive bass (proximity effect) with close-mic techniques.

Sound Field Mono
Operating Principle Pressure Gradient
Transducer Condenser
Diaphragm 1" / 25.40 mm
Tube No
Polar Pattern Cardioid
Frequency Range 20 Hz to 20 kHz
Signal to Noise Ratio 85 dB
Equivalent Noise Level 9 dB A-Weighted
Maximum SPL 140 dB SPL
Pad -10 dB
-20 dB
Impedance 125 Ohms
Load Impedance 1 kOhms
Sensitivity 30 mV/Pa
Connectivity 3-pin male XLR connector
Low-Cut Filter 6 dB/Octave @ 80 Hz6 dB/Octave @ 160 Hz
Output Connectors 1 x 3-Pin XLR
Operating Current Consumption 6 mA
Operating Voltage 48 V

Dimensions & Weight
  • Diameter: Diameter: 58mm (2.28 in)
  • Length: 169mm (6.65 in)
  • Weight: 445 g (15.70 oz.)
