M4350-16V4C Fully Managed Switch (VSM4320C)
Netgear

M4350-16V4C Fully Managed Switch (VSM4320C)

16xSFP28 25G and 4xQSFP28 100G Managed Switch
Product Highlights
  • 16 x 25G SFP28 Ports
  • 4 x 100G QSFP28 Ports
  • 1.6 Tb/s Switching Capacity
  • 1190.4 Mpps Forwarding Rate
  • Rackmount Design
  • Secondary PSU Slot
  • Intelligent Fan Cooling
  • Optimized for AV-Over-IP Multicasts
  • Netgear Engage Controller Support

  • Overview
  • Tech Specs

Designed primarily for high-bandwidth AV and IT applications, this network switch includes 16 SFP28 ports that support up to 25 Gb/s fiber connections.

With Netgear's IGMP Plus, the M4350-16V4C switch delivers smooth video-over-IP multicasts with little to no setup required. Four 100G QSFP28 ports are available for uplinks and stacking. Installing a separately purchased second power supply provides 1+1 redundancy. This switch works with Netgear's Engage Controller management platform, in addition to standard command line and web-based interfaces.

Performance
With a 1.6 Tb/s switching capacity and 1190.4 Mpps forwarding rate, this switch is designed to provide smooth and reliable AV broadcasts.

Multicast in an InstantNetgear IGMP Plus provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
The intelligent fans may be configured in Quiet Mode to help minimize noise or Cool Mode for maximum cooling. Mounting ears are included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 and M4250 switches, supporting nonstop forwarding stacking, spine and leaf topology, and core to edge connectivity.

Fast, Easy Configuration
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

Primary Port Speed 25 Gigabit
Number of Ports 20 (16 x 25G SFP28, 4 x 100G QSFP28)
PoE Ports / Budget N/A
IGMP Support Enhanced (NETGEAR IGMP Plus™)
Jumbo Frame Support Yes, up to 12kb
AVB Support Yes, included
Acoustics Quiet Mode 33.4dB@25°C
Power Consumption 143.4W/450.28Btu/hr
Standby without any port connection: 60.4W/189.66Btu/hrr
Power Consumption APS600Wv3
APS1200Wv2
APS2000Wv2

Dimensions
  • Width: 440mm
  • Depth: 400mm
  • Height: 43.2mm
  • Weight: 7.15kg (15.77lb)
