Blackmagic URSA Mini Recorder
Record 12-bit Blackmagic RAW files onto fast 2.5 inch SSDs, including the latest 7mm U.2 NVMe Enterprise SSDs which transfer data at speeds of up to 900 MB/s
Product Highlights
- For URSA Mini Pro 12K Camera
- Single-Slot 2.5" SSD Card Recorder
- Supports up to 12K 12-Bit Raw Files
- Works with U.2 NVMe Enterprise Disks
- Molex Connector to Battery Plate
- Attaches between Camera & Battery
- Overview
- Tech Specs
Blackmagic URSA Mini Recorder lets you record Blackmagic RAW files onto 2.5 inch NVMe based 7mm U.2 SSD’s or standard 2.5 inch SSD Media with your URSA Mini Pro 12K! That means you can use commonly available and inexpensive high capacity solid state media! The NVMe based SSD media can record full resolution 12K, 8K and 4K 12‑bit RAW files plus it comes in much larger sizes so you can record longer without having to change disks!
| Connections | |
| Computer Interface | 1 x USB Type-C 3.1 Gen 2 with locking screw for bidirectional data link with URSA Mini Pro 12K and software updates. |
| Media | |
| Media | 1 x 2.5 inch SSD for 4K, 8K and 12K recording. |
| Supported Codecs | |
| Supported Codecs | Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Bitrate 18:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5. |
| Environmental Specifications | |
| Operating Temperature | 5° C to 40° C (41° - 104° F) |
| Storage Temperature | -10° to 60° C (14° to 140° F) |
| Relative Humidity | 0% to 90% non-condensing |
| Physical Specifications | |
| Width | 86.5 mm |
| Height | 143.11 mm |
| Depth | 43 mm |
| Weight | 585 g |
Operating Systems
- Mac
Mac 10.14 Mojave,
Mac 10.15 Catalina or later. - Windows
Windows 10.
Power Requirements
- Power Connection12-pin Molex connector with passthrough to battery plate.
